High Clearance Drag Box
The High Clearance Drag Box has been engineered specifically to allow pipes to pass into the trench with minimum hindrance, facilitating a quicker progression along the length of the trench.
- The largest working envelope on the market.
- Telescopic struts for easy adjustment in 150mm increments.
- Extension boxes can be used as base boxes.
- Panel Height 3.2m.
- Please allow 3 working days for wide load delivery.
Categories: Excavation, Ground Support, Groundworks, Pipe laying
Product Description
Base Box(mm) | Ext. Box(mm) | |
---|---|---|
Vertical Clearance below rear strut | 2278 | 875 |
Vertical Clearance below front strut | 1225 | 430 |
Horizontal Clearance between struts | 4500 | 4500 |
Strut Type | Internal Width(mm) | External Width(mm) | Base Box | Ext. Box(mm) | ||
---|---|---|---|---|---|---|
Min. | Max. | Min. | Max. | Weight (Kg) | Weight (Kg) | |
Fixed | 600 | 600 | 800 | 800 | 3970 | 2330 |
Fixed | 800 | 800 | 1000 | 1000 | 3846 | 2446 |
Fixed | 1000 | 1000 | 1200 | 1200 | 3876 | 2476 |
Telescopic | 1200 | 1500 | 1400 | 1700 | 4270 | 2870 |
Telescopic | 1500 | 2100 | 1600 | 2300 | 4462 | 3062 |
Telescopic | 2100 | 3300 | 2300 | 3500 | 4844 | 3444 |
Telescopic | 3000 | 5100 | 3200 | 5300 | 5434 | 4034 |
